ADS62P48IRGCT
Texas Instruments
IC ADC 14BIT PIPELINED 64VQFN
1556 Pcs New Original In Stock
14 Bit Analog to Digital Converter 2 Input 2 Pipelined 64-VQFN (9x9)
Request Quote
(Ships tomorrow)
*Quantity
Minimum 1
Minimum 1
5.0 / 5.0
- (481 Ratings)
ADS62P48IRGCT
Product Overview
1389505
DiGi Electronics Part Number
ADS62P48IRGCT-DGManufacturer
Texas Instruments
ADS62P48IRGCT
Description
IC ADC 14BIT PIPELINED 64VQFNInventory
1556 Pcs New Original In Stock
14 Bit Analog to Digital Converter 2 Input 2 Pipelined 64-VQFN (9x9)
Quantity
Minimum 1
Minimum 1
Purchase and inquiry
Warranty & Returns
How to Order
Shipping & Delivery
Quality Assurance
365 - Day Quality Guarantee - Every part fully backed.
90 - Day Refund or Exchange - Defective parts? No hassle.
Limited Stock, Order Now - Get reliable parts without worry.
Global Shipping & Secure Packaging
Worldwide Delivery in 3-5 Business Days
100% ESD Anti-Static Packaging
Real-Time Tracking for Every Order
Secure & Flexible Payment
Credit Card, VISA, MasterCard, PayPal, Western Union, Telegraphic Transfer(T/T) and more
All payments encrypted for security
ADS62P48IRGCT Technical Specifications
Category
Data Acquisition, Analog to Digital Converters (ADC)
Packaging
Cut Tape (CT) & Digi-Reel®
Series
-
Product Status
Active
Number of Bits
14
Sampling Rate (Per Second)
210M
Number of Inputs
2
Input Type
Differential
Data Interface
LVDS - Parallel, Parallel
Configuration
S/H-ADC
Ratio - S/H:ADC
1:1
Number of A/D Converters
2
Architecture
Pipelined
Reference Type
External, Internal
Voltage - Supply, Analog
3.15V ~ 3.6V
Voltage - Supply, Digital
1.7V ~ 1.9V
Features
Simultaneous Sampling
Operating Temperature
-40°C ~ 85°C
Package / Case
64-VFQFN Exposed Pad
Supplier Device Package
64-VQFN (9x9)
Mounting Type
Surface Mount
Base Product Number
ADS62P48
Datasheet & Documents
HTML Datasheet
ADS62P48IRGCT-DG
Environmental & Export Classification
RoHS Status
ROHS3 Compliant
Moisture Sensitivity Level (MSL)
3 (168 Hours)
REACH Status
REACH Unaffected
ECCN
3A991C3
HTSUS
8542.39.0001
Additional Information
Other Names
296-24611-2-NDR
296-24611-2-DG
296-24611-1-DG
296-24611-6-NDR
296-24611-6-DG
296-ADS62P48IRGCTDKR
-296-24611-1-DG
-ADS62P48IRGCT-NDR
296-24611-6
296-24611-1-NDR
296-24611-1
2156-ADS62P48IRGCT
296-ADS62P48IRGCTTR
296-ADS62P48IRGCT
296-24611-2
TEXTISADS62P48IRGCT
-296-24611-1-NDR
Standard Package
250
Alternative Parts
PART NUMBER
MANUFACTURER
QUANTITY AVAILABLE
DiGi PART NUMBER
UNIT PRICE
SUBSTITUTE TYPE
Reviews
5.0/5.0-(Show up to 5 Ratings)
de desembre 02, 2025
Die Produkte sind präzise, langlebig und gut designt. DiGi Electronics ist mein bevorzugter Anbieter.
de desembre 02, 2025
サービスの質が非常に高く、安心して利用できます。
de desembre 02, 2025
The team responded promptly to all my questions, demonstrating excellent service.
de desembre 02, 2025
The durability and reliability of their products are truly commendable.
de desembre 02, 2025
Always on track with delivery times, which helps us meet our commitments.
de desembre 02, 2025
I'm impressed by how dependable Di Digi Electronics hardware is—great quality at a reasonable price.
Publish Evalution
Evalution Message
Please enter your review message.
Please post honest comments and do not post ilegal comments.
Frequently Asked Questions (FAQ)
What are the key design-in risks when using the ADS62P48IRGCT in a high-channel-count data acquisition system with tight power budgets?
When integrating the ADS62P48IRGCT into high-channel-count systems, a major design risk is cumulative power dissipation. While the ADS62P48IRGCT operates efficiently at 210MSPS with dual 14-bit pipelined ADCs, each channel consumes approximately 760 mW at 3.3V analog and 1.8V digital supplies. In systems with multiple ADCs, thermal buildup and power supply routing become critical. To mitigate this, use split power planes, optimize PCB copper for thermal dissipation under the exposed pad, and consider staggered data capture windows to reduce peak current. Additionally, ensure the LVDS parallel interface termination resistors are tightly matched to avoid skew across channels, which can degrade effective resolution in simultaneous sampling applications.
How does the ADS62P48IRGCT compare to the ADS62P49IRGCT when selecting for signal-to-noise ratio (SNR) and spurious-free dynamic range (SFDR) in wideband receiver designs?
When choosing between the ADS62P48IRGCT and the ADS62P49IRGCT for wideband applications, the key trade-off lies in performance versus power. The ADS62P48IRGCT delivers 72.5 dBFS SNR and 85 dBc SFDR at 180 MHz input, while the ADS62P49IRGCT offers slightly better 73.5 dBFS SNR and 87 dBc SFDR but at 250 mW higher power per channel. If your design prioritizes energy efficiency in dense multichannel systems—such as in portable test equipment or remote radio heads—the ADS62P48IRGCT is preferable. However, if your system demands the highest dynamic range (e.g., military or instrumentation receivers), upgrading to the ADS62P49IRGCT may be worth the extra power and thermal management complexity.
What are the critical layout considerations for maintaining signal integrity with the ADS62P48IRGCT's differential analog inputs at 210MSPS?
To preserve signal integrity with the ADS62P48IRGCT at maximum sampling rates, maintain strict differential pair routing: keep trace lengths matched within 10 mils and use controlled impedance of 100Ω differential across the input path. Use a continuous ground plane beneath traces and avoid splits or vias near the ADC input pins. The 64-VQFN (9x9) package has tight pin pitch, so fanout should use micro-vias if necessary to prevent crosstalk. Additionally, place the 0.1µF bypass capacitors for analog and digital supplies as close as possible—ideally within 2 mm—of their respective supply pins, and use a low-inductance connection to the exposed thermal pad, which must be grounded solidly to reduce noise coupling.
Can the ADS62P48IRGCT replace the MAX1427 in an existing pipeline ADC design, and what are the major compatibility risks?
Replacing the MAX1427 with the ADS62P48IRGCT presents several integration challenges despite both being 14-bit pipelined ADCs. The ADS62P48IRGCT runs at 210MSPS (vs. MAX1427’s 80MSPS), so timing constraints on the parallel LVDS interface are much stricter, requiring precise skew management in digital data lines. The input range differs (1.8Vpp differential typical on ADS62P48IRGCT vs. 2Vpp on MAX1427), so driver amplifier gain stages must be adjusted. Additionally, the power domains are split (3.3V analog, 1.8V digital) in the ADS62P48IRGCT, requiring dual supplies versus a single 3V rail for the MAX1427. A complete review of timing budget, power delivery, and reference voltage configuration is required to avoid performance degradation during replacement.
What reliability issues should be considered when deploying the ADS62P48IRGCT in industrial environments operating near the upper temperature limit of 85°C?
When deploying the ADS62P48IRGCT in industrial applications approaching 85°C, long-term reliability depends on robust thermal design and signal stability. The MSL 3 rating means the device is sensitive to moisture absorption; if exposed to humidity before assembly, it must be baked or reflowed within 168 hours. Beyond assembly, operating near the maximum junction temperature can accelerate electromigration and degrade ADC linearity over time. To mitigate this, ensure the exposed pad is fully soldered to a large copper thermal land with multiple vias to inner ground planes. Monitor junction temperature via die temperature sensors if available, and avoid continuous 210MSPS operation at high ambient temps without adequate airflow or heat sinking. Derating the sample rate to 180MSPS can significantly improve thermal margin and reliability.
