FSAM30SM60A
onsemi
SMART POWER MODULE 30A SPM32-AA
1208 Pcs New Original In Stock
Power Driver Module IGBT 3 Phase 600 V 30 A 32-PowerDIP Module (1.370", 34.80mm)
Request Quote
(Ships tomorrow)
*Quantity
Minimum 1
Minimum 1
5.0 / 5.0
- (352 Ratings)
FSAM30SM60A
Product Overview
7828342
DiGi Electronics Part Number
FSAM30SM60A-DGManufacturer
onsemi
FSAM30SM60A
Description
SMART POWER MODULE 30A SPM32-AAInventory
1208 Pcs New Original In Stock
Power Driver Module IGBT 3 Phase 600 V 30 A 32-PowerDIP Module (1.370", 34.80mm)
Quantity
Minimum 1
Minimum 1
Purchase and inquiry
Warranty & Returns
How to Order
Shipping & Delivery
Quality Assurance
365 - Day Quality Guarantee - Every part fully backed.
90 - Day Refund or Exchange - Defective parts? No hassle.
Limited Stock, Order Now - Get reliable parts without worry.
Global Shipping & Secure Packaging
Worldwide Delivery in 3-5 Business Days
100% ESD Anti-Static Packaging
Real-Time Tracking for Every Order
Secure & Flexible Payment
Credit Card, VISA, MasterCard, PayPal, Western Union, Telegraphic Transfer(T/T) and more
All payments encrypted for security
FSAM30SM60A Technical Specifications
Category
Power Driver Modules
Packaging
-
Series
Motion SPM® 2
Product Status
Obsolete
Type
IGBT
Configuration
3 Phase
Current
30 A
Voltage
600 V
Voltage - Isolation
2500Vrms
Mounting Type
Through Hole
Package / Case
32-PowerDIP Module (1.370", 34.80mm)
Base Product Number
FSAM30
Datasheet & Documents
HTML Datasheet
FSAM30SM60A-DG
Environmental & Export Classification
Moisture Sensitivity Level (MSL)
1 (Unlimited)
REACH Status
REACH Unaffected
ECCN
EAR99
HTSUS
8542.39.0001
Additional Information
Other Names
FSAM30SM60A_NL
FSAM30SM60A-NDR
FSAM30SM60A_NL-DG
Standard Package
48
Alternative Parts
View DetailsPART NUMBER
MANUFACTURER
QUANTITY AVAILABLE
DiGi PART NUMBER
UNIT PRICE
SUBSTITUTE TYPE
Reviews
5.0/5.0-(Show up to 5 Ratings)
de desembre 02, 2025
가격 경쟁력과 사용자 경험 모두 뛰어난 곳입니다.
de desembre 02, 2025
Their commitment to meeting delivery deadlines and providing high-quality products makes them stand out.
de desembre 02, 2025
I appreciate the consistent professionalism in their packaging standards.
de desembre 02, 2025
The responsiveness of customer service team ensures I get help whenever I need it.
de desembre 02, 2025
I highly value their quick reponse to after-sales issues, demonstrating real commitment.
de desembre 02, 2025
I was very pleased with how smoothly my order was delivered, thanks to their reliable logistics and support.
Publish Evalution
Evalution Message
Please enter your review message.
Please post honest comments and do not post ilegal comments.
Frequently Asked Questions (FAQ)
Can FSAM30SM60A be used in new designs given its obsolete status, and what are the long-term supply chain risks?
The FSAM30SM60A is marked as obsolete by onsemi, meaning it's no longer recommended for new designs due to declining availability and eventual discontinuation. While 1105 units are currently in stock, ongoing production support is not guaranteed. For long-term reliability and supply continuity, consider migrating to active-design-equivalent solutions like the FNB43060T2, which offers comparable 600V, 30A SPM-3 integration but with better availability and extended lifecycle support. Designers should assess end-product lifespan and inventory needs before committing to FSAM30SM60A.
How does the FSAM30SM60A perform in high-temperature motor drive applications, and what thermal management considerations are critical?
The FSAM30SM60A integrates IGBTs and driver circuitry in a compact 32-PowerDIP module, making thermal management crucial in sustained high-load motor control applications. Due to its 30A rating and lack of an integrated heatsink, effective PCB layout with wide copper planes, thermal vias, and optional forced-air cooling are essential to prevent hotspot formation. Monitor case temperature closely—keeping it below 100°C ensures reliable operation, especially in enclosed environments where ambient temperatures exceed 70°C.
Is the FSAM30SM60A a drop-in replacement for the FNB43060T2 in an existing PMSM inverter design?
The FSAM30SM60A and FNB43060T2 are functionally similar 600V, 30A 3-phase IGBT modules but are not direct drop-in replacements due to differences in pinout, drive circuitry, and package dimensions. While both belong to onsemi’s SPM® family, the FNB43060T2 uses a smaller DIP-27 package with updated gate drive logic. A redesign of the PCB layout and verification of bootstrap circuit timing is required when substituting FSAM30SM60A with FNB43060T2. Always consult both datasheets for gate threshold compatibility and shoot-through prevention.
What are the risks of using the FSAM30SM60A in industrial inverter designs without external current sensing?
The FSAM30SM60A includes basic protection features but lacks integrated current sensing, relying on external shunt resistors or Hall sensors for overcurrent detection in precision motor control. Omitting external sensing risks undetected phase overloads, leading to device failure under stall or short-circuit conditions. For robust design-in, implement a low-inductance shunt resistor on the DC-link or each phase leg with filtering to avoid false triggering, ensuring timely fault response through the controller.
How does the 2500Vrms isolation rating of the FSAM30SM60A impact safety compliance in 240VAC-driven HVAC systems?
The FSAM30SM60A's 2500Vrms isolation meets or exceeds IEC 60747-7 and UL 1577 requirements for reinforced insulation in residential HVAC motor drives operating from 240VAC lines. This enables reliable creepage and clearance performance in line-powered inverters, reducing risk of ground faults or transient breakdown. However, ensure PCB layout maintains ≥8mm creepage distance around isolation barriers and use conformal coating in high-humidity environments to preserve long-term reliability under real-world operating stresses.
